Representative equipment image60T Wide-Body Mining TruckWide-Body Mining Truck
A 60,000 kg rated-payload wide-body mining truck with a struck body capacity of 29.5–34 m³ (heaped 36–40 m³) and 460 HP engine output. Final configuration is confirmed against the intended mine, haul profile and order requirements.
A 60,000 kg rated payload for surface haulage.
This wide-body mining truck configuration is intended for on-site and short-haul work in open-pit mines and aggregate operations. Payload, haul distance, ramp grade, loading equipment, material density and local operating conditions should be reviewed together before configuration is confirmed.
Capacity, powertrain and overall dimensions.
Capacity
- Rated payload
- 60,000 kg
- Empty weight
- 31,700 kg
- Gross vehicle weight
- 91,700 kg
Overall dimensions
- Overall length
- 8,840 mm
- Overall width
- 3,550 mm
- Overall height
- 4,050 mm
Powertrain
- Engine
- WEICHAI WP12G460E310
- Engine output
- 460 HP
- Transmission
- FAST 7DS200 / FC6A210
Chassis
- Axle load
- 20 + 35 + 35 t
- Tyre
- 14.00-25 / 14.00R25
- Min ground clearance
- 310 mm
Body
- Body capacity (struck)
- 29.5–34 m³
- Body capacity (heaped)
- 36–40 m³
Performance
- Max speed (unladen)
- 45 km/h
- Max speed (laden)
- 45 km/h
- Max gradeability
- 30 %
- Min turning diameter
- 22 m
Start with the haul profile and operating environment.
Check the machine envelope against site access.
Review approved equipment views.
What the current product record confirms.
What is the rated payload?
The current reviewed product record lists a rated load of 60,000 kg.
What engine configuration is listed?
The current record lists a Weichai WP12G460E310 engine with 460 HP output.
What body capacity is listed?
The listed body capacity is 36 m³.
Are price and availability shown on this page?
No. Configuration, commercial terms and availability must be confirmed for the intended site and order.
Ask about this truck.
Start with one contact method and a short equipment request. We can confirm site conditions and configuration during follow-up.
